Stewarts of America has experience in development, design and innovation of pinned products for many textile applications.

Non-Woven

Stewarts manufactures and supplies a wide variety of parts for Non-Woven machinery to include:

• Pinned Lift Aprons for Bale Openers
• Pre Opener / Fine Opener Pinned Lags
• Hopper Feeder / Cross Lapper Spiked Lattices and Aprons
• Mini Non-woven Lines
• Stenter Frames
• Waste Recycling / Edge Opening
• New and Used Machinery

Stewarts is the North American agent and has global partnerships with several companies:

• MCCART - a global sales network of used textile machinery - www.macart.com
• BASANT WIRE – Manufacturer of pins and pinned products in India – www.bwipins.com
• FALLER BARS INTERNATIONAL – steel and disposable faller bars, chains etc. for gill boxes – www.fallerbars.com
• PERFORATION MACHINERY LTD – Perforation Machinery built in the UK for the European market – www.perforationmachinery.com
• TATHAM - a worldwide manufacturer of non-woven machinery. Specializing in mini laboratory scale lines, Tatham manufacture unique, custom, technical textile processing equipment - www.tatham-uk.com

Solving problems for textile customers around the world is our specialty.
Stewarts of America has long been involved in all sectors of the textile industry. We also have the ability to refurbish and rebuild existing textile machinery. We have worldwide partnerships and representation to be able to assist you, no matter where you are located.

Re-pinning and Repair Services

Because of the nature of Stewarts of America's pinning technology, it is often possible for us to remove and replace some or all the pins in your existing pinned product. If your pinned product is damaged or worn, contact us to see if it is worthwhile and/or possible.
Contact us for more info on Non-Woven Solutions

DREF Friction Spinning Machinery

Stewarts of America manufactures components for Fehrer DREF Friction spinning equipment. Stewarts also offers new and used Fehrer DREF Friction spinning machinery.

Recognizing that there was a need by our customers, Stewarts have developed a solid base of spare parts for Fehrer DREF friction spinning equipment and now offer a wide verity of parts to include both mechanical and electrical components.

Stewarts offers parts to include the perforated spinning cylinders, combing rolls, suction tubes and more for:

• Fehrer DREF 2 (DREF II) (both Gen 1 an Gen 2)
• Fehrer DREF 3 (DREF III)
• Fehrer DREF 2000
• Fehrer DREF 3000
• Other fiction spinning machines

Stewarts of America has modified high wear machine components such as the perforated cylinders, suction tubes and motors to make them work more efficiently, even with tough materials such as fiberglass, Nomex and Kevlar. Working together with our customers worldwide, Stewarts offer a wide array parts and modifications that allow new and unique yarns to be made by this equipment, and to make parts for these machines more accessible.

Fehrer DREF Refurbishing

Stewarts can take an existing Fehrer DREF spinning machine, completely tear it down, and build it back completely refurbished. We offer electrical drive conversions, part upgrades and technical expertise.

Naturally, we are in touch with mills worldwide and are often the first to know about used equipment that comes available to the marketplace. The difference is we know the technical spinning industry. We are also experts in the mop yarn industry, we offer worldwide support and consultation for this field.

We can offer machinery for mop yarn spinning such as the Ingolstadt RU04, RU14 and RL10 machines. We also manufacture Rotor cups, navels / doff tubes, combing rolls and other components for these machines. (See the Open End Spinning Section for more details.)
Contact us for more info on DREF Solutions

Waste Opening

Pinned lags - Whether you have a LaRoche, Dell'Orco and Villini, Margasa, Marlasca, Italia Regeneratzione, Temafa, Autefa or other waste opening unit, Stewarts can manufacture pinned lags for your cylinders. We offer standard pin configurations and completely custom configurations for unorthodox applications. Our waste opening pins are designed to penetrate and open fiber effectively but gently, keeping as much staple length as possible. The pins are designed to maximize opening and keep long life, while minimizing friction.

Stewarts of America offers pinned aluminum and wooden lags for all textile recycling machinery.

From interlocking tongue and groove lags, to flat lags with scallops, Stewarts has made pinned lags for the textile industry for over 130 years. We have the designs for all the OEM lags, and specialize in placing custom pin patterns in cylinders to achieve unique opening capabilities. We have worked with tough to open fibers such as carpet, Kevlar and other materials. We can convert opening machinery that currently does not do the job, to super openers!

The Waste opening / textile recycling process is tough on pins. The process can generate lots of heat from friction and sparks from metallic debris that are processed with used clothing and other post-consumer materials. This heat can cause breakdown of the holding capability of the pins in the metallic lag. Solving this problem led Stewarts of America to innovate with our latest technology – The Excalibur™ pins – The pin that will not liberate! Using a clever pin and hole technology combination, we keep the price of the technology low, while utilizing the benefits of a mechanical fit.

Stewarts also uses our pin pattern layout technology to optimize the opening effect on fibers. This makes opening more efficient and generates less friction. All our pinned lags are machined on our state of the art CNC machining centers to ensure precise pin hole placement, pattern and tolerances. Bolt holes are machined at the same time, thus providing highly accurate mounting locations to align with customer's existing cylinders.

Unique Design
The unique design of interlocking aluminum alloy staves have firmly established themselves in the world's fiber industries with its extended life and strength. Over 5 million being supplied to well over 55 countries over the past 80 years and their accuracy and long life are now legendary. Indeed some of the original staves are still running after many re-pinnings. For high density pinning, our staves have now demonstrated their accuracy and reliability over some 25 years.

Interlocking Staves
The interlock between our staves means that the staves in front and behind each stave contribute to the total strength of the assembly, and greatly reduce the chances of a catastrophic damage in a card smash.

Pinned and Wire Mini-Trim Cylinders
Edge trim and mini-trim openers come in a wide verity of widths and diameters. Stewarts covers them all.

Fewer Screw Holes
Fewer retaining screws are needed because of the strength of the aluminum alloy together with the patented interlock. This means less gaps in the pinning, improved carding and easier maintenance. In many cases the staves and lags can be made double width, further reducing the problem. However the screw holes are still placed so that the aluminum staves can be fitted in place of wooden staves without modification.

Here are some of the main advantages:

• Lightweight, high strength aluminum alloy construction
• Interlocking fit; virtually smash proof
• Fewer screw holes; Easier fitting and removal
• Fire Resistant; Unaffected by humidity
• Carbon steel pins give extra long life in aluminum
• Indefinite number of re pinnings possible
• Easy re-pinning with pins
• Double width lags for even easier replacement
• Extra high pin-point density using "N.I.F" pinning
• Field proven for over 60 years in over 50 countries
• Greatly extended life gives excellent value for money

Re-pinning and Repair Services

Because of the nature of Stewarts of America's pinning technology, it is often possible for us to remove and replace some or all the pins in your existing pinned product. If your pinned product is damaged or worn, contact us to see if it is worthwhile and/or possible.
Contact us for more info on Waste Opening Solutions

Blow Room, Opening + Carding

Stewarts of America manufactures a wide variety of products for blow room, opening and carding machinery.

Stewarts manufactures both pinned lags, pinned and wire rollers for cleaning and opening machinery such as Trutzschler's CVT and Rieter's ERM and Unimix systems, amongst many other OEM machinery. Chances are, if you have one of these machines, you already have our pinned products in your machinery. We have the original specifications and drawings for many of these rollers as we are the manufacturer of choice for many textile machinery makers worldwide.

Carding - Chute Feed and Licker/Taker in Rolls and Bars

Stewarts is involved in two areas of the carding machinery. Stewarts manufactures pinned cylinders and bars for chute feed applications and pinned and wire licker ins. Pinned licker ins are sometimes used alone against the main carding cylinder, or may be included in a 3-roller cassette, such as in a Trutzschler cards, where the pinned roller takes the brunt of the primary opening work.

Chute feed rollers come in various configurations:

• Straight pinned bars, extruded shaped, square bar or T bar
• Spiral pinned rollers
• Straight pinned rollers

Licker in rollers:

• Wire rollers
• Pinned rollers in either 25ppsi or 36ppsi configurations

Spiked Lattices with Aluminum or Wooden Pinned Bars

Stewarts supplies a wide range of Spiked Lattices for Feed Hoppers, Conveyors and Bale Openers. Used for transporting, lifting and opening. Stewarts offers standard lattices as per OEM specifications, and custom made lattices if required. Spiked/Pinned lattices are manufactured with quality carbon steel pins which allow for long production life and high precision. Spiked Lattices can be made to any length to include the extended lengths now required for Non-woven applications.

A wide range of pinning specifications are available depending on your application and requirements which can be tailored to suit.

Improve Your Existing Machinery

Stewarts will work with you to make the pinned products easier to replace, maintain and change out. We can offer help with improving efficiencies and fiber opening effectiveness.

Re-pinning and Repair Services

Because of the nature of Stewarts of America's pinning technology, it is often possible for us to remove and replace some or all the pins in your existing pinned product. If your pinned product is damaged or worn, contact us to see if it is worthwhile and/or possible.
Contact us for more info on Waste Opening Solutions

Drafting + Combing

Pinned Strips and Pinned Faller Bars for Gill Boxes and Combing:

• For Wool, Silk and Synthetic Fibers
• For NSC, Sant Andrea, Cognetex, Textima, OKK And other makes Of Gill Boxes

Faller Plastic Pinstrips:
Stewarts supplies a full range of Press Fit type Pinstrips with advantages of long long life, excellent fiber opening, quick remounting of fallers and economical prices. 2.5 to 9 PPCM / up to 300 mm pin set over /11 to 25 mm pin height.

Faller bars available for most leading chain driven machines, both high and low back, with various set overs, pin projections and the option of flat or round-pins.

Disposable Fallers

Disposable faller bars for NSC Schlumberger GC and Sant Andrea CSN chain gill boxes.

The large diameter steel core is machined on CNC lathes and precision bending tools. The steel core is presented to the injection moulding machine and the colored plastic is molded to the steel core and the keyed pins in one operation. The plastic is color coded for pins per cm. Color coded end rollers are fitted as standard.

All fallers are inspected for quality control.

Fallers are manufactured in eight options:

• Left Hand (LH) or Right Hand (RH)
• 220mm or 270mm working pinned field
• High Back (HB) or Low Back (LB)
• Round or Flat polished steel keyed pins for HB or LB fallers

Steel Fallers

Stewarts supplies Steel faller bars for NSC Schlumberger GC and Sant Andrea CSN chain gill boxes.

The manufacturing process and quality checks for high quality unpinned steel fallers bars includes:

• CNC machining of special profile Cold Drawn Profiled carbon steel
• Precision tool bending
• Heat treatment
• Straightening and final quality control
• Plastic end roller and circlip fitted
• All fallers are inspected for quality control

The fallers are manufactured in six options:

• Left Hand (LH) or Right Hand (RH)
• 220mm or 270mm working pinned field
• High Back (HB) or Low Back (LB)

The fallers are suitable for Press Fit Inserts.

Inserts

Stewarts supplies Steel Fallers for NSC GN Screw Gills and Cognetex system gills are also available.

• NSC Schlumberger GC Chain Gills
• NSC Schlumberger GV Vertical Gills
• NSC Schlumberger GN Screw Gills
• Sant Andrea CSN Chain Gills
• Sant Andrea VSN Screw Gills
• Mackie Screw and Chain Gills
• HMG Chain Gills
• Cognetex Chain Gills

Chains

The universal drafting head of the Schlumberger GC chain gill requires chains of high quality to allow speeds of up to 400m/min.

We supply new chains pitch 9.525mm part ref no 423A152M. Four Chains are required per GC machine. The chains are in stock for immediate delivery. Several thousand chains sold with repeat orders demonstrates our product quality.

For NSC GC Chain gills we manufacture in several options:

• Press Fit Insert
• 220mm or 270mm working pinned field
• High Back (HB) or Low Back (LB)
• Round or Flat polished steel keyed pins for HB or LB fallers
• The plastic is color coded for pins per cm

Stewarts also offers:

• Insert Mounting Machinery
• Low cost, Maintenance free, Portable machine for quick and easy remounting of inserts in faller bars
• Gill Box Head Spares
• Combs for Almeters for worsted fiber testing
• Brass Gills for bast fibers, such as jute, flax, sisal, hemp, etc.
• Used machinery

Contact us for more info on Drafting + Combing Solutions

Open End Spinning

Stewarts of America manufactures a number of components for open end spinning machinery. Whether you have a Schlafhorst, Rieter, Savio, Investa, Ingolstatdt or other open end spinning frame. We have many of the OEM technical drawings to make the parts for your requirements.

Rotor Cups

Stewarts manufactures just about any rotor cup you require, any diameter and any groove. All dynamically balanced to OEM specification.

We also offer just about any coating you may require:

• Diamond
• Diamond Nickel
• Boron Diamond
• Boron Nickel
• Boron
• Nickel

Stewarts of America was the first manufacturer of open end spinning parts in America. Now, we are the last. Parts made in the USA.

Navel / Doff Tubes

Stewarts manufactures navels and doff tubes to any OEM or custom specifications. Navels can be made in steel or with ceramic inserts. We offer grooved navels and navels with roughing devices if required.

Combing Rolls

Stewarts manufacture a wide verity of combing rolls and ring. Both pinned and wire. We offer a wide array of wire types. These wires are used with an array of coating. Made to OEM or custom specifications.

We are not restricted to, but commonly used wires are:

• CPT-63
• CM-13
• B174
• OS21
• OB20

Contact us for more info on Open End Spinning Solutions

Finishing

Stenter Pinned Plates + Selvedge Pin Wheels for Finishing
Stewarts of America supplies pinned tenter/steter plates for most machinery manufacturers such as Kenyon, Monforts, Krantz, Babcock, Winsor & Jerauld, Fabcon, Artos, Harish, Entec, Marshall & Williams, Famatex, Bruckner, Corino, Entec, Fabcon, Tubetex, Hunter, Morrison, Mascoe, Proctor & Schwartz, Gessner, Ewa, Muzzi, Tandematic, Texima, Santex, Singer, Santa Lucia, Tacker, Liba, American Liba and Stentex.

Brass pin plates for all leading brands of Stenters with hardened, mirror finished, extra fine tipped pins.

Pinned plates for multi-axial warp knitting and weaving machines to include Karl Meyer / Liba / American Liba models such as:

• Biaxtronic
• Cop Biax 2
• Cop Max 4
• Cop Max 5
• Maxtronic
• And other makes and models…

Stewarts can also supply a new unique designed hard poly plate for low cost, light weight, non-corroding, non-marking for light to medium fabrics. Made with thermoplastic material that withstands up to 240°C. These pinned plates can house carbon steel or stainless steel pins with 8 to 72 pins per plate, 0.08 to 2mm diameter of pins, 9.5 to 20mm length of pins.

Stewarts of America also manufactures aluminum pin wheels that are utilized in selvedge trimming and fabric guiding. We offer a wide verity of designs and sizes. We can provide you with the pin wheels that you need for your specific type of tenter frame or guiding system you utilize.
Contact us for more info on Finishing Solutions

Weaving

Stewarts of America provides Temples for Weaving Looms for manufacturers including Sulzer, Dornier, Tsudakoma, Toyota, Picanol, Nuouo Pignone, Vamatex, Somet, Saurer and other makes of Shuttleless Looms.

Temple cylinders are available in various configurations of rings; spiked, plain or rubber to suit various fabrics and to avoid temple marks. We also design custom solutions for special fabrics.

• Precisely fitted, free moving rings
• Hardened and polished pins
• Variable pin height in blunt and sharp profiles
• Parallel as well as progressive ring arrangements

Spiked Brass or Nylon Rings:

• 1 row to 5 row
• 12 to 36 rings per row
• 0.25 to 3.00 mm pin height
• Sharp or blunt type
• Nylon or Teflon bush

Rubber Rings and Dummy Rings are also available.

• Durable rubber quality
• Good grip property
• Stainless steel tube and polished insert pipe

Brass Rollers in various shapes and sizes, to customer specifications. Pin height 0.25 to 2.00 mm and up to 50 pins per sq. inch.
Contact us for more info on Weaving Solutions

Used/Pre-Owned Textile Machinery

Stewarts of America purchases and sells many different types of used textile equipment for yarn manufacturing, open end spinning, friction spinning, fiber and waste recycling, non-wovens, and other industries. Machinery is sold and brokered directly from our warehouse inventory or straight off the mill floor. Please contact us if you have any specific machinery requirements. As a manufacturer of parts for textile machinery, we have contacts all over the globe, and we are often the first to know about available machinery. The ability to machine and manufacture parts also makes Stewarts unique, as we can manufacture parts to refurbish or modify machinery we find on the used market. We specialize in older, hard to find open end spinning machinery and DREF spinning machinery.

Stewarts are experts in worldwide logistics, and move machinery all over the world on a regular, reliable basis.

Stewarts is the North American agents for TATHAM, worldwide manufacturer of non woven machinery, and supplier of used textile machinery.
Contact us for more info on Used Textile Machinery
